GroWall Pond & Living Shoreline Wall Kits

Beautiful, Green Alternative to Shoreline Restoration

• Beautiful, green alternative for shoreline restoration.
• Easy to install- no extensive footings or foundations necessary, and no extensive anchors required.
• Quicker and easier than using stone or coir logs.
• Perfect for low to medium water energy.
• Protects water quality and purifies run-off.
• Creates local habitat for insects, birds, and aquatic creatures.
• Creates a reinforced shoreline with a natural look.
• Easy to vegetate: Use live plants, bare root shrubs, or sod.

GroWall by Envirolok is a vegetative alternative to traditional hardscape walls and shorelines. GroWall is simple to install, easy to permit, and designed for DIY installations, small-scale landscape design, and home projects. The non-woven geotextile bags permanently encapsulate the soil for maximum stability. The one-of-a-kind connection system provides strength, making the entire system strong and long-lasting. The GroWall system supports plant growth by allowing roots to grow through the bags and lock into the soil beneath, providing strong reinforcement and creating beautiful, fully vegetated projects that will stand the test of time.

Shoreline erosion can be a challenging and costly battle. GroWall's shoreline protection kits offer a green alternative to coir logs, rip rap, or hard armoring. These kits are ideal for DIY installations along the edges of ponds, lakes, streams, or any place that water meets land. In addition to the engineered strength of the GroWall system, Pond & Shoreline Protection Kits include patented stabilizer strips to help secure the system against wave action, ice, and debris

Note:

• GroWall can be combined with hard armoring for a vegetative buffer or used above the water level to encapsulate the shoreline and reduce erosion on high-energy shorelines.
• Do NOT cut the bags to insert plant material.
• Installation is recommended during low water levels or times of no wake.
• Purchaser is responsible for all permitting, and approvals required in your location.

Each GroWall Pond & Living Shoreline Kit contains:

• GroWall Bags
• Closure Ties
• 2 Connection Pins (per bag)
• 2 Stabilizer Strips (per bag)

What you need to get started

• Bag Fill (80% Sand/ 20% Topsoil)
• Tape Measure, Shovel, Hand Tamper, Hard Rake, Safety Glasses, Contractors Bucket (Optional)
• Plants (2.5” Pot or smaller) / Sod

How do I determine how many bags I’ll need?

We recommend determining the height and length of your project first. A filled bag will be approximately 2 feet long, and 4 inches tall. From there, calculate the number of bags that you need and order the corresponding kit size.

Height (Feet) / .33(Feet) = # of Bags High

Length (Feet) / 2 (Feet) = # of Bags Long

# of Bags High x # of Bags Long = # of Bags You Will Need

Example: You are looking to install GroWall bags along a shoreline that is 30 feet long and needs to be 1.5 feet tall.

Height: 1.5ft / 0.33ft = 5 Bags High (Rounded Up)

Length: 30ft / 2ft = 15 Bags Long

5 x 15 = 75 GroWall Bags Needed

Choose the Best Kit Option for You:

• 50 Bag Kit: 25-30 exposed face feet – Approximately 6-8 inches tall by 30 linear feet. (Requires 1.5 cy of bag-fill, 50-100 Plant Plugs)
• 75 Bag Kit: 30-40 exposed face feet - Approximately 10-12 inches tall by 30 linear feet. (Requires 2 cy of bag-fill, 100-150 Plant Plugs)
• 100 Bag Kit: 45-50 exposed face feet - Approximately 18-20 inches tall by 30 linear feet. (Requires 3 cy of bag-fill, 150-200 Plant Plugs)

Installation Summary
